Design and development of signal conditioning circuit for MEMS based piezo-resistive pressure sensor for aerospace and defense applications
DOI:
https://doi.org/10.58368/MTT.23.1-2.2024.20-25Keywords:
MAX1452, Signal Conditioning, Filter, CompensationAbstract
MEMS (Micro Electro Mechanical System) technology is the latest ongoing technology in the current world. Various sensors are being developed using this technology for aerospace and defense applications. The MEMS based piezo-resistive pressure sensors that are fabricated are initially in the die form, integrated with signal conditioning circuit and are packaged suiting to aerospace and defense applications. In this research MAX1452, a highly integrated analog-sensor signal processor optimized for industrial and process control applications is used for signal conditioning which involves amplification, calibration, and temperature compensation. Here an experiment was conducted to interface the wheat-stone bridge sensing circuit to MAX1452, calibrated for set of temperatures, temperature compensated and further tested the signal conditioning circuit with off the shelf available MEMS pressure sensor.
Metrics
References
ENDEVCO. (n.d.). Piezoresistive pressure transducer Model 8530B. https://www.pcbpiezotronics.fr/ wp-content/uploads/8530B_DS_082219.pdf
John, P. C., Joshi, A., Sindhanakeri, P., Ajayakumar, P. D., & Natarajan, K. (2010). Signal conditioner for MEMS based piezoresistive sensor. 5th International Conference on Industrial and Information Systems, Mangalore, India, 329-333, doi: 10.1109/ICIINFS.2010.5578683
Matzen, S. M., Johannesen, P., & Danfoss Sensing Solutions. (n.d.). Innovative pressure transmitter signal conditioning with Danfoss QDCTM excitation. In White Paper. sensors.danfoss. com. https://assets.danfoss.com/documents/ latest/206048/BE414869549421en-000101.pdf
Maxim Integrated. (2015). MAX1452 Low-Cost Precision Sensor Signal Conditioner. https:// www.analog.com/media/en/technical-documentation/data-sheets/MAX1452.pdf
Step-by-Step procedure for performing temperature compensation using MAX1452 and MAX1455 evaluation kit software. (n.d.). Analog Devices. https://www.analog.com/en/resources/ technical-articles/stepbystep-procedure-for-performing-temperature-compensation.html
Yao, Z., Liang, T., Jia, P., Hong, Y., Qi, L., Lei, C., Zhang, B., & Xiong, J. (2016). A high-temperature piezoresistive pressure sensor with an integrated signal-conditioning circuit. Sensors, 16(6). https://doi.org/10.3390/s16060913
